Products Description
HUGANG - Single jib portal crane is confirming with harbor portal crane technical specifications, safety specifications, and design standards. It is mostly used in shipyards, wharfs, loading and unloading places. The revolving part of the crane is mounted on the portal base. The portal base is actually the load-bearing part of the crane. A traveling mechanism is installed under the portal base, which can travel on the track set on the ground. The rotating part is equipped with a boom and lifting, rotating, and luffing mechanism. Four mechanisms work together to complete the installation of equipment or hull segments, or to carry out cargo loading and unloading.
Technical Parameters
|
Model |
Lifting Capacity (t) |
Working Range(m) |
Lifting Height (m) |
Working Speed |
|||||
|
Min. |
Max. |
Above Rail |
Below Rail |
Lifting (m/min) |
Luffing (m/min) |
Slewing (m/min) |
Traveling (m/min) |
||
|
MQ1018 |
10 |
6.5 |
18 |
12 |
6 |
40 |
30 |
1.46 |
15 |
|
MQ1025 |
10 |
8.5 |
25 |
13 |
8 |
35 |
28 |
1.2 |
20 |
|
MQ1030 |
10 |
8.5 |
30 |
25 |
15 |
60 |
52 |
1.5 |
26 |
|
MQ1033 |
10 |
9.5 |
33 |
16 |
15 |
60 |
50 |
1.5 |
25 |
|
16 |
9.5 |
22 |
25 |
40 |
|||||
|
MQ1633 |
16 |
9.5 |
33 |
25 |
15 |
55 |
55 |
1.48 |
25 |
|
25 |
9.5 |
22 |
30 |
||||||
|
MQ163 |
16 |
10 |
35 |
22 |
15 |
55 |
55 |
1.5 |
25 |
|
25 |
10 |
25 |
18 |
30 |
|||||
|
MQ2533 |
25 |
10 |
33 |
26 |
16 |
50 |
50 |
1.4 |
25 |
|
35 |
10 |
25 |
|||||||
|
MQ4025 |
40 |
9 |
19 |
12 |
15 |
18 |
18 |
1 |
26 |
|
25 |
9 |
25 |
30 |
||||||
|
MQ4035 |
40 |
11 |
30 |
23 |
12 |
18 |
24 |
1 |
25 |
|
35 |
11 |
35 |
|||||||
Components of Single Jib Portal Crane
Port portal cranes have lifting, slewing, luffing and running mechanisms. The first three mechanisms are installed on the rotating part and participate in operations in each cycle. The rotating part is also equipped with a pitchable tilting single arm frame or combined arm frame and a driver's cab. The operating mechanism is installed at the lower part of the portal to adjust the working position of the crane. The portal crane with bucket is also equipped with additional equipment such as telescopic funnels and belt conveyors to improve the productivity of the portal crane when loading and unloading bulk materials with grabs. In addition to electrical protection devices, safety devices such as lifting weight or lifting moment limiters, crane rail clamps, etc. are also installed.
Features & Advantages
* Versatility: With its ability to move back and forth, and up and down, the portal jib crane can be used to lift and transport goods of various sizes and shapes. This versatility makes it a reliable and essential tool for businesses of all sizes.
* High Efficiency: The portal jib crane is designed to make the lifting and transporting of goods as easy and quick as possible. With its smooth operation and precision engineering, it can perform tasks quickly and efficiently, saving time and reducing labor costs.
* Safety: It is equipped with safety features such as limit switches, anti-collision devices, and overload protection, to ensure the safety of operators and surrounding personnel. This makes it a safe and reliable option for companies who prioritize safety in their operations.
